conveRt to R: the short course

# conveRt to R: the short course
### Chris Hanretty
### January 2020

---

# Unit 5: Modelling strategies

---

# Reminder

```r
library(tidyverse)
library(rio)
library(huxtable)
```

otherwise things will not work
]

---

# Contents

- Simpler models
 - OLS
 - Binary models
 - Count models
 - Ordered and unordered categorical models
 - Model plots, marginal effects

]
.pull-right[
 - Models mostly for identification
 - IV
 - Diff-in-diff
 - RDD
 - Coarsened exact matching
 - Multilevel modelling
]

---

# Ordinary least squares

Let's take a fuller look at some of the arguments...
]

```r
lm(formula, data, subset, weights, na.action,
   method = "qr", model = TRUE, x = FALSE, y = FALSE, qr = TRUE,
   singular.ok = TRUE, contrasts = NULL, offset, ...)
```
.small[
I have never used most of these arguments, but some are useful:
]

- `weights`: supply a weight variable: `lm(y ~ x, data = dat, weights = dat$w8)`

- `subset`: just pass a different value of the `data` argument. `lm(y ~ x, data = subset(dat, foo = TRUE))`.
 - `offset`: can pass a constant to include, but it's better to include this in the model formula, as long as it's in the data frame (`lm(y~x + offset(my_offset)`)
]

---

# OLS bonuses

R has pretty good visual regression diagnostics for `lm` models:

```r
data(anscombe)
mod <- lm(y3 ~ x3,
          data = anscombe)
plot(mod)
```
]
.pull-right[
![](unit004_files/figure-html/anscombeout-1.png)

]
---

# Dichotomous outcomes

From `lm` (**l**inear **m**odel), we move to `glm` (**generalized** linear model).

The formula syntax remains the same. What changes is the `family` argument.
.pull-left[
.small[

```r
bes <- rio::import("bes_f2f_2017_v1.5.dta")
bes <- characterize(bes)
bes <- bes %>%
  mutate(voted = validatedTurnoutBinary == "Voted")

mod <- glm(voted ~ edlevel,
           data = bes,
           family = binomial)
huxreg(mod)
```
]
]
.pull-right[
.small[

<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(1)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.669 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.134)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelBelow GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.698 *  </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.338)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelGCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.052    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.197)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelNo qualifications</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.243    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.183)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelPostgrad</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.900 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.258)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelUndergraduate</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.734 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.178)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">1449        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-812.031    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">1636.062    </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]
]

---

# Dichotomous extras

- `binomial` is actually a function which takes a further argument, `link`. We ran a logit model. We could have run a probit model by calling:

```r
mod2 <- glm(voted ~ edlevel, data = bes,
           family = binomial(link = "probit"))
```

- If you want, you could specify other link functions, like a `cauchit` or `cloglog` link function. You monster.

 - Like many models, we can use broom to `tidy` or `glance` at the model object.

```r
glance(mod2)
```

<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 95.5555555555556%; margin-left: 0%; margin-right: auto;  ">
<col><col><col><col><col><col><col><tr>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">null.deviance</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">df.null</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">BIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">deviance</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">df.residual</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1.65e+03</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1448</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">-812</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1.64e+03</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1.67e+03</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1.62e+03</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1443</td>
</tr>
</table>

- If you want more (and more informative) statistics about fit, try `hitmiss` in the `pscl` package.

---

# Count models - Poisson and negative binomial

We can use `glm` to specify a Poisson model, by changing the `family` argument.

Let's look at the count of days in the week respondents discuss politics.

```r
bes <- bes %>%
  mutate(discuss_days = recode(u01,
                               "Don`t know" = NA_integer_,
                               "Five days" = 5L,
                               "Four days" = 4L,
                               "No days" = 0L,
                               "One day" = 1L,
                               "Seven days" = 7L,
                               "Six days" = 6L,
                               "Three days" = 3L,
                               "Two days" = 2L))
```

Why `NA_integer_` and `5L`? Because `recode` really wants to know we're dealing with integers.

This is a noticeably tricky issue with `recode`.

---

# A Poisson model is probably not sensible...

```r
p <- ggplot(bes, aes(x = discuss_days)) +
  geom_histogram() +
  scale_x_continuous("Days in week R discusses politics") +
  scale_y_continuous("Number of respondents")
  theme_bw()
```
]

```
## `stat_bin()` using `bins = 30`. Pick better value with `binwidth`.
```

```
## Warning: Removed 29 rows containing non-finite values (stat_bin).
```

![](unit004_files/figure-html/histdiscussout-1.png)
]

---

```r
mod <- glm(discuss_days ~ edlevel,
           data = bes,
           family = poisson)
huxreg("Poisson model" = mod)
```

```
## Warning in huxreg(`Poisson model` = mod): Unrecognized statistics: r.squared
## Try setting `statistics` explicitly in the call to `huxreg()`
```
]
]

.pull-right[
<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">Poisson model</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.662 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.038)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelBelow GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.116    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.085)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelGCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.081    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.057)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelNo qualifications</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.472 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.056)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelPostgrad</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.516 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.054)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelUndergraduate</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.300 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.045)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">2127        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-4622.657    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">9257.314    </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]

---

# Count models - negative binomial

You're waiting for me to tell you we can run a negative binomial model just by changing the `family` argument?

Ha, sucks to be you. **No**, we need to load a new package, called `MASS`, and use function `glm.nb`. Let's try that now.

```r
library(MASS)
```

```
##
## Attaching package: 'MASS'
```

```
## The following object is masked from 'package:dplyr':
##
##     select
```

```r
mod <- glm.nb(discuss_days ~ edlevel,
           data = bes)
```

Huh? Masked? What's that all about?

---

# R package conflicts

One major advantage of R is that it is a **decentralised open source system**.

The downside of this is that people can use the same function names, and these can clash.

R is telling us that now, when we call `select`, it will use the version of `select` that comes from MASS.

This function -- which carries out ridge regression for the purposes of variable selection -- is very different from the version we have been using from the tidyverse/dplyr.

To over-ride this behaviour, we should start using the double-colon notation. For example:

```r
bes <- bes %>%
  dplyr::select(var1, var2, var2)
```

---

# Categorical models - ordered outcomes

.small[
It's just as well that we loaded `MASS`, because we need another function in MASS to carry out ordered logistic regression models.

Let's predict an ordered outcome -- how much interest the respondent has in politics.

This is in the `bes` data as variable `a03`.

```r
table(bes$a03, useNA = "always")
```

```
##
##            Don`t know     Fairly interested Not at all interested
##                     2                   978                   270
##   Not very interested       Very interested                  <NA>
##                   493                   451                     0
```

In order to run an ordered logistic regression, we need our dependent variable to be an **ordered factor**.
]

---

# Ordered factors

Creating the ordered factor requires us to specify all the levels.

```r
bes <- bes %>%
  mutate(interest = factor(a03,
                           levels = c("Not at all interested",
                                      "Not very interested",
                                      "Fairly interested",
                                      "Very interested"),
                           ordered = TRUE))
```

Levels not included become `NA`...

```r
table(bes$a03, bes$interest)
```

```
##
##                         Not at all interested Not very interested
##   Don`t know                                0                   0
##   Fairly interested                         0                   0
##   Not at all interested                   270                   0
##   Not very interested                       0                 493
##   Very interested                           0                   0
##
##                         Fairly interested Very interested
##   Don`t know                            0               0
##   Fairly interested                   978               0
##   Not at all interested                 0               0
##   Not very interested                   0               0
##   Very interested                       0             451
```
]

---

# `polr`

```
## Warning in FUN(X[[i]], ...): tidy() does not return p values for models of class
## data.frame; significance stars not printed.
```

```
## Warning in huxreg(mod): Unrecognized statistics: r.squared
## Try setting `statistics` explicitly in the call to `huxreg()`
```

<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(1)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelBelow GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.206 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.206)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelGCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.024 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.143)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelNo qualifications</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.538 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.129)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelPostgrad</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">1.371 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.163)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelUndergraduate</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.842 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.122)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Not at all interested|Not very interested</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-1.828 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.111)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Not very interested|Fairly interested</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.407 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.100)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Fairly interested|Very interested</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">1.747 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.108)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">2154.000 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-2635.753 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">5287.506 </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]

---

# I see no stars!

Brian Ripley, author of the MASS package.
]
.pull-right[
You'll notice that there are no significance stars in the last table.

`huxreg` relies on `broom::tidy`, and `broom::tidy` results on `MASS::summary.polr`.

`summary.polr` doesn't report p-values because the package author has... **opinions** on p-values.
]

---

# Over-riding p-values

```r
coef_vals <- broom::tidy(mod) %>%
    mutate(abs_tval = abs(statistic),
           pval = pnorm(abs_tval, lower.tail = FALSE) * 2)

fixed_mod <- tidy_override(mod,
                           p.value = coef_vals$pval,
                           extend = TRUE)

huxreg(fixed_mod)
```

```
## Warning in huxreg(fixed_mod): Unrecognized statistics: r.squared
## Try setting `statistics` explicitly in the call to `huxreg()`
```
]
.pull-right[
<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(1)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelBelow GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.206    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.206)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelGCSE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.024    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.143)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelNo qualifications</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.538 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.129)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelPostgrad</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">1.371 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.163)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">edlevelUndergraduate</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.842 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.122)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Not at all interested|Not very interested</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-1.828 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.111)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Not very interested|Fairly interested</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.407 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.100)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Fairly interested|Very interested</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">1.747 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.108)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">2154.000    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-2635.753    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">5287.506    </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]

---

# Categorical models - unordered outcomes

Another Brian Ripley-authored package is `nnet`, from which we can use `nnet::multinom`, for unordered outcomes.

Here's the obvious vote choice multinomial regression.

```r
library(nnet)
bes <- bes %>%
  mutate(vote = dplyr::recode(b02,
                              "Green Party" = "Green",
                              "Independent" = "Other",
                              "Other" = "Other",
                              "Don`t know" = NA_character_,
                              "Conservatives" = "Con",
                              "Labour" = "Lab",
                              "Liberal Democrats" = "LDem",
                              "None/No party" = NA_character_,
                              "Refused" = NA_character_,
                              "Plaid Cymru" = "PC",
                              "Scottish National Party (SNP)" = "SNP",
                              "United Kingdom Independence Party (UKIP)"= "UKIP"))
mod <- multinom(vote ~ edlevel, data = bes)
```

```
## # weights:  56 (42 variable)
## initial  value 3381.171947
## iter  10 value 2107.939424
## iter  20 value 2002.506081
## iter  30 value 1991.505583
## iter  40 value 1990.238490
## iter  50 value 1990.186638
## final  value 1990.186421
## converged
```

---

# Predictions

No-one understands multinomial regression coefficients, no one!

Let's bind the columns of our predictions together with our example data.

(`cbind` = merge when you are sure about row order).

```r
newdata <- data.frame(edlevel = unique(bes$edlevel))
preds <- predict(mod, newdata, type = "prob")
newdata <- cbind(newdata, preds)
head(newdata)
```

<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 100%; margin-left: 0%; margin-right: auto;  ">
<col><col><col><col><col><col><col><col><col><tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">edlevel</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">Con</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">Green</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">Lab</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">LDem</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">Other</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">PC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">SNP</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">UKIP</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">No qualifications</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.452</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.00308</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.412</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0277</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.00308 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.00923 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0431</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0492 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">Below GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.514</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.0135 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.378</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.0541</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">1.69e-09</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">5.12e-08</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.027 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0135 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">Undergraduate</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.391</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0212 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.428</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0991</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.00531 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0195  </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0283</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.00708</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">Postgrad</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.266</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.0435 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.516</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.125 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">8.96e-09</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.00543 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.0326</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0109 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">A-level</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.368</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.02   </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.504</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.048 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">2.69e-08</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.012   </td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.028 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.02   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.469</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0175 </td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.395</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0482</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">8.06e-10</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0219  </td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0132</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.0351 </td>
</tr>
</table>

Hmm... this looks like it might be difficult to plot. Can we turn it into a long format?

---

# Plotted predictions

```r
plot.df <- pivot_longer(newdata,
                        -edlevel,
                        names_to = "party",
                        values_to = "probability")

p1 <- ggplot(plot.df,
       aes(x = party,
           y = probability,
           fill = party)) +
  facet_wrap(~edlevel) +
  geom_bar(stat = "identity")
```

]
.pull-right[

```
## Warning: Removed 8 rows containing missing values (position_stack).
```

![](unit004_files/figure-html/pivotpredplotsout-1.png)
]

---

# Improving that plot

.small[
 - Remove the NA row in plot.df (`plot.df <- subset(plot.df, !is.na(edlevel))`)
 - Make `edlevel` an ordered factor; ggplot will respect this ordering.
 - Change the theme to something less busy
]

```r
p1 <- p1 + theme_bw()
```

.small[
 - Pass party-specific colours (see list at [http://sape.inf.usi.ch/quick-reference/ggplot2/colour](http://sape.inf.usi.ch/quick-reference/ggplot2/colour):
 ]

```r
p1 <- p1 +
  scale_fill_manual(values = c("darkblue", "green3",
    "firebrick3", "goldenrod", "darkgrey", "greenyellow",
    "yellow", "orchid4"))
```

```r
p1 <- p1 +
  theme(legend.position = "bottom")
```
.small[
 - Rotate the horizontal axis labels
]

```r
p1 <- p1 +
  theme(axis.text.x = element_text(angle = 90))
```

---

# An improved plot

---

# Margins

.pull-left[
![Margins sticker](margins_sticker.png)
]
.pull-right[
Often, we are not interested in predicted values, but in marginal effects.

This is particularly true for **discrete outcomes** and for **interactions**.

For these we can use Thomas Leeper's excellent `margins` package.

```r
install.packages("margins", dependencies = TRUE)
```
]

---

# Margins for multinomial objects

The object below shows the average marginal effect of moving from the middle category (A-level education) to any other discrete category on the probability of voting Conservative.

```r
library(margins)
mm <- margins(mod, category = "Con")
summary(mm)
```

<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 57.7777777777778%; margin-left: 0%; margin-right: auto;  ">
<col><col><col><col><col><col><col><tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">factor</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">AME</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">SE</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">z</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">p</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">lower</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">upper</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">edlevelBelow GCSE</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.146 </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">edlevelGCSE</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.101 </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">edlevelNo qualifications</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0843</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">edlevelPostgrad</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">-0.102 </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">edlevelUndergraduate</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.0232</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);"></td>
</tr>
</table>

Please note: standard errors for average marginal effects in multinom models are still being developed.

---

# Margins for interactions

Suppose we have an interaction between two continuous variables.

Specifically, suppose we think the effect, upon Conservative vote
share, of a constituency having a lot of pensionsers depends on
whether lots of people in the area own their house or not.

```r
agg <- import("BES-2017-General-Election-results-file-v1.0.xlsx")
mod <- lm(Con17 ~ Con15 + c11HouseOwned * c11Age65to74,
   data = agg)
huxreg(mod)
```
]
.pull-right[
<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(1)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-20.779 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(2.979)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">Con15</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.789 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.012)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">c11HouseOwned</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.354 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.048)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">c11Age65to74</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">3.707 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.470)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">c11HouseOwned:c11Age65to74</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.036 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.007)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">631        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">R2</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.925    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-1800.003    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">3612.007    </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]

What does this mean?

---

# Showing average marginal effects

```r
marg1 <- margins(mod)
summary(marg1)
```

---

# Plotting marginal effects across a variable

Let's see the effects of a unit change in house ownership by the
proportion of those aged 65 to 74.

This code follows very closely the example used in [the docs](https://github.com/leeper/margins).

```r
plot.df <- cplot(mod,
                 x = "c11Age65to74",
                 dx = "c11HouseOwned",
                 what = "effect",
                 draw = FALSE)

ggplot(plot.df, aes(x = xvals)) +
    geom_ribbon(aes(ymin = lower, ymax = upper), fill = "gray70") +
    geom_line(aes(y = yvals)) +
    xlab("Proportion of constituency aged 65 to 74") +
    ylab("Average Marginal Effect of house ownership") +
    theme_bw()
```
]
.pull-right[
![](unit004_files/figure-html/margins2-1.png)

]

---

# Let's try that again

```r
plot.df <- cplot(mod,
                 dx = "c11Age65to74",
                 x = "c11HouseOwned",
                 what = "effect",
                 draw = FALSE)

ggplot(plot.df, aes(x = xvals)) +
    geom_ribbon(aes(ymin = lower, ymax = upper), fill = "gray70") +
    geom_line(aes(y = yvals)) +
    xlab("Proportion of constituency owning their house") +
    ylab("Average Marginal Effect of proportion aged 65 to 74") +
    theme_bw()
```
]
.pull-right[
![](unit004_files/figure-html/margins3-1.png)
]

---

# Unit 5b: Models mostly for identification

---

# Instrumental variables

An instrumental variables allows us to estimate the effect of some treatment by finding an instrument which affects the treatment but not the outcome.

Here, we'll use data from the AER package, which investigates the effect of college on earnings:

**Treatment:** years of education

**Outcome:** hourly wage in US dollars

**Instrument:** distance from a 4-year college while growing up, in tens of miles.

**Controls:** gender and ethnicity, parental college attendance, location

We'll first estimate this using two-stage least squares using `lm(...)`, and then use a handier function.

---

# IV in steps

First, let's load the package...

```r
library(AER)
```

```
## Loading required package: car
```

```
## Loading required package: carData
```

```
##
## Attaching package: 'car'
```

```
## The following object is masked from 'package:dplyr':
##
##     recode
```

```
## The following object is masked from 'package:purrr':
##
##     some
```

```
## Loading required package: lmtest
```

```
## Loading required package: zoo
```

```
##
## Attaching package: 'zoo'
```

```
## The following objects are masked from 'package:base':
##
##     as.Date, as.Date.numeric
```

```
## Loading required package: sandwich
```

```
## Loading required package: survival
```

---

# IV in steps (2)

And now the data and code...

```r
data("CollegeDistance")
dat <- CollegeDistance
treat_mod <- lm(education ~ distance +
                    gender + ethnicity +
                    mcollege + fcollege +
                    urban + region,
                data = dat)
dat$pred_education <- predict(treat_mod, newdata = dat)
outcome_mod <- lm(wage ~ pred_education + gender +
                      ethnicity +
                      mcollege + fcollege +
                      urban + region,
                  data = dat)
huxreg("Treatment" = treat_mod,
       "Outcome" = outcome_mod)
```
]
.pull-right[
<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">Treatment</td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">Outcome</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">13.714 ***</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">9.150 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.054)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(2.304)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">distance</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.052 ***</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.011)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">genderfemale</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.018    </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.059    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.050)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.039)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">ethnicityafam</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.381 ***</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.601 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.070)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.083)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">ethnicityhispanic</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.053    </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.407 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.067)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.053)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">mcollegeyes</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.644 ***</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.034    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.079)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.128)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">fcollegeyes</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.950 ***</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.036    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.068)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.174)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">urbanyes</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.021    </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.009    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.062)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.048)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">regionwest</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.152 *  </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.272 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.064)   </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.057)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">pred_education</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">        </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.045    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">        </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.169)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">4739        </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">4739        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">R2</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.104    </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.042    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-9220.556    </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-8019.247    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">18461.112    </td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">16058.495    </td>
</tr>
<tr>
<td colspan="3" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]
---

# Alternately, using `AER::ivreg`

```r
mod <- ivreg(wage ~ education +
                 gender + ethnicity +
                 fcollege + mcollege +
                 urban + region |
                 gender + ethnicity +
                 fcollege + mcollege +
                 urban + region +
                 distance,
             data = dat)
huxreg(mod)
```

```
## Warning in huxreg(mod): Unrecognized statistics: logLik, AIC
## Try setting `statistics` explicitly in the call to `huxreg()`
```
]
.pull-right[
<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(1)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">9.150 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(2.308)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">education</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.045    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.170)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">genderfemale</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.059    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.039)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">ethnicityafam</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.601 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.083)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">ethnicityhispanic</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.407 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.053)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">fcollegeyes</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.036    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.175)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">mcollegeyes</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.034    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.128)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">urbanyes</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.009    </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.048)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">regionwest</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.272 ***</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(0.057)   </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">4739        </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">R2</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.039    </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]
---

# Difference-in-difference designs

We don't need to spend much time on this, since diff-in-diff is just a
particular type of interaction.

Here's some pseudo-code:

```r
dat <- dat %>%
    mutate(treated = ifelse(iso3c %in% c("CAN", "NZL"),
                            1,
                            0),
           time_after_treat = year - 2006)
mod <- lm(y ~ treated * time_after_treat, data = dat)
```

---

# Regression discontinuity designs

Regression discontinuity design: any design where the value of a
treatment variable changes suddenly at a certain value of a continuous
"running variable".

There are multiple R packages for analysing RDDs:

- rdd
 - rddtools
 - rdrobust

My preference is for `rdrobust`, because it is recent and does well
with bandwidth selection.

---

# Example

Legal access to alcohol in the United States is governed by a sharp
discontinuity in the running variable age.

What effect does this have on all-causes mortality?

Let's use data from Angrist and Pischke's *Mastering Metrics*...

```r
dat <- rio::import("http://masteringmetrics.com/wp-content/uploads/2015/01/AEJfigs.dta")
```

**Question:** do you remember how to inspect the labels for the
variables in data imported from Stata?

---

# Generate a plot

```r
dat <- dat %>%
    mutate(can_drink = agecell >= 21)

ggplot(dat, aes(x = agecell, y = mva,
                colour = can_drink)) +
    geom_point() +
    geom_smooth(se = FALSE) +
    theme_bw() +
    scale_colour_discrete(guide = "none") +
    scale_x_continuous("Age") +
    scale_y_continuous("Mortality rate per 100,000") +
    labs(title = "Deaths due to motor vehicle accidents") +
    geom_vline(xintercept = 21)
```

```
## `geom_smooth()` using method = 'loess' and formula 'y ~ x'
```

```
## Warning: Removed 2 rows containing non-finite values (stat_smooth).
```

```
## Warning: Removed 2 rows containing missing values (geom_point).
```
]
.pull-right[

```
## `geom_smooth()` using method = 'loess' and formula 'y ~ x'
```

![](unit004_files/figure-html/plotrdd-1.png)
]

---

# Estimate the discontinuity

Where `y` is the outcome variable, `x` the running variable, and `c`
the numeric cut-off ...

```r
library(rdrobust)
mod <- rdrobust(y = dat$mva, x = dat$agecell, c = 21)
summary(mod)
```

```
## Call: rdrobust
##
## Number of Obs.                   48
## BW type                       mserd
## Kernel                   Triangular
## VCE method                       NN
##
## Number of Obs.                  24          24
## Eff. Number of Obs.              6           6
## Order est. (p)                   1           1
## Order bias  (q)                  2           2
## BW est. (h)                  0.488       0.488
## BW bias (b)                  0.738       0.738
## rho (h/b)                    0.660       0.660
## Unique Obs.                     24          24
##
## =============================================================================
##         Method     Coef. Std. Err.         z     P>|z|      [ 95% C.I. ]
## =============================================================================
##   Conventional     4.900     2.058     2.381     0.017     [0.867 , 8.934]
##         Robust         -         -     1.882     0.060    [-0.196 , 9.670]
## =============================================================================
```

No data argument, how rude!

No `huxtable` or `broom` methods for rdrobust yet...

---

# Matching methods

Let's load the library (install if you haven't done so)

```r
library(cem)
```

```
## Loading required package: tcltk
```

```
## Loading required package: lattice
```

```
##
## How to use CEM? Type vignette("cem")
```

---

# Matching Lalonde

```r
data("LL", package = "cem")
```
]
.pull-left[
**treated** treatment variable indicator

**age** age

**education** years of education

**black** race indicator variable

**married** marital status indicator variable

**nodegree** indicator variable for not possessing a degree
]
.pull-right[
**re74** real earnings in 1974

**re75** real earnings in 1975

**re78** real earnings in 1978 (post-treatment outcome)

**hispanic** ethnic indicator variable

**u74** unemployment in 1974 indicator variable

**u75** unemployment in 1975 indicator variable
]

**Query:** What is the effect of treatment on real earnings in 1978?

---

# Simple conditioning on observables

```r
mod <- lm(re78 ~ treated + re75 + re74 +
              u75 + u74 +
              nodegree + married +
              black + hispanic,
          data = LL)
huxreg(mod, coefs = c("Treatment" = "treated"))
```

---

# Coarsened exact matching

```r
cemobj <- cem(treatment = "treated",
    data = LL,
    drop = c("re78"))
print(cemobj)
```
]
.pull-right[

```
##            G0  G1
## All       425 297
## Matched   222 163
## Unmatched 203 134
```
]

```r
att(cemobj, re78 ~ treated, data = LL)
```
]
.pull-right[

```
##
##            G0  G1
## All       425 297
## Matched   222 163
## Unmatched 203 134
##
## Linear regression model on CEM matched data:
##
## SATT point estimate: 550.962564 (p.value=0.368242)
## 95% conf. interval: [-647.777701, 1749.702830]
```
]

CEM estimate is around 2/3rds of the OLS estimate...

---

# Multilevel modelling

Load the library...

```r
library(lme4)
```

```
## Loading required package: Matrix
```

```
##
## Attaching package: 'Matrix'
```

```
## The following objects are masked from 'package:tidyr':
##
##     expand, pack, unpack
```

```
## Registered S3 methods overwritten by 'lme4':
##   method                          from
##   cooks.distance.influence.merMod car
##   influence.merMod                car
##   dfbeta.influence.merMod         car
##   dfbetas.influence.merMod        car
```

```
##
## Attaching package: 'lme4'
```

```
## The following object is masked from 'package:rio':
##
##     factorize
```

---

# New syntax!

It's been a while since we saw a new language element or fun keyboard character.

It's the turn of the vertical bar (|) to shine.

Here's how we specify some different multilevel models:

A regression where each `school` has a different (random) intercept:

```r
depvar ~ indvar + (1|school)
```

A regression where the effect of `indvar` varies across school:

```r
depvar ~ 1 + (indvar|school)
```

A regression where there is a main effect of `indvar` and a random coefficient:

```r
depvar ~ indvar + (indvar|school)
```

---

# More generally

![](lme4.png)

**Source: ** Bates, D. M., Maechler, M., Bolker, B. M., & Walker,
S. (2015). Fitting linear mixed-effects models using lme4. *Journal of
Statistical Software* 67 (1): 1–48.

---

# Example multilevel model

```r
data("InstEval", package = "lme4")
```
.pull-left[
.small[
**s** a factor with levels **1:2972** denoting individual students.

**d** a factor with 1128 levels from **1:2160**, denoting individual
     professors or lecturers.

**studage** an ordered factor with levels **2** < **4** < **6** < **8**,
     denoting student's “age” measured in the _semester_ number
     the student has been enrolled.

**lectage** an ordered factor with 6 levels, **1** < **2** < ... < **6**,
     measuring how many semesters back the lecture rated had taken
     place.
]
]
.pull-right[
.small[
**service** a binary factor with levels **0** and **1**; a lecture is a
     “service”, if held for a different department than the
     lecturer's main one.

**dept** a factor with 14 levels from **1:15**, using a random code
     for the department of the lecture.

y a numeric vector of _ratings_ of lectures by the students,
     using the discrete scale **1:5**, with meanings of **poor** to
     **very good**.

Each observation is one student's rating for a specific lecture
(of one lecturer, during one semester in the past)
]
]

---

# A possible model

This model will take a minute or so to estimate, so I **save** the
model object using the RDS format. I only estimate the model if the
save file doesn't exist.

```r
if (file.exists("saved_lmer_mod.rds")) {
    mod <- readRDS("saved_lmer_mod.rds")
} else {
    mod <- lmer(y ~ service + studage + lectage + (1|dept) +
                    (1|s) + (1|d),
                data = InstEval)
    saveRDS(mod, file = "saved_lmer_mod.rds")
}
```

---

# Getting the details of the model

By default, huxreg will report fixed effects.

```r
huxreg(mod)
```

Notice how the regression uses the fact that the factors are
ordered. I never use this, and always remove the order from my factors
before using them in a regression.

(g)lmer models don't include p-values for... reasons [1](https://stat.ethz.ch/pipermail/r-help/2006-May/094765.html) [2](http://bbolker.github.io/mixedmodels-misc/glmmFAQ.html#testing-hypotheses)

If you need p-values, check out package `lmerTest`.

]
.pull-right[
.small[
<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 50%; margin-left: auto; margin-right: auto;  ">
<col><col><tr>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: center; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.8pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(1)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">3.224 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.030)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">service1</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.073 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.013)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">studage.L</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.096 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.019)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">studage.Q</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.006 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.016)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">studage.C</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.017 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.016)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">lectage.L</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.186 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.016)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">lectage.Q</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.023 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.012)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">lectage.C</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.024 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.013)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">lectage^4</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.021 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.013)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">lectage^5</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-0.039 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(0.015)</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">sd__(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">0.327 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(NA)     </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">sd__Observation</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">1.176 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;"></td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(NA)     </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">N</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">73421     </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">logLik</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">-118809.479 </td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">AIC</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.8pt 0pt; padding: 4pt 4pt 4pt 4pt;">237646.958 </td>
</tr>
<tr>
<td colspan="2" style="vertical-align: top; text-align: left; white-space: normal; padding: 4pt 4pt 4pt 4pt;"> *** p < 0.001;  ** p < 0.01;  * p < 0.05.</td>
</tr>
</table>

]
]
---

# Getting the random effects out

```r
library(broom.mixed)
tmp <- broom.mixed::tidy(mod, effects = "ran_vals")
tmp %>%
    filter(group == "s") %>%
    arrange(desc(estimate)) %>%
    head()
```

<table class="huxtable" style="border-collapse: collapse; margin-bottom: 2em; margin-top: 2em; width: 64.4444444444444%; margin-left: 0%; margin-right: auto;  ">
<col><col><col><col><col><col><tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">effect</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">group</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">level</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">term</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">estimate</td>
<td style="vertical-align: top; text-align: right; white-space: nowrap; border-style: solid solid solid solid; border-width: 0.4pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt; font-weight: bold;">std.error</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">ran_vals</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">s</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">1163</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.871</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.151</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">ran_vals</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">s</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">2732</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.835</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.183</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">ran_vals</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">s</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">700</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.794</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.174</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">ran_vals</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">s</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">2785</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt;">0.744</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.189</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0pt 0.4pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">ran_vals</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">s</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">2945</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: normal; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.737</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0pt 0pt; padding: 4pt 4pt 4pt 4pt; background-color: rgb(242, 242, 242);">0.167</td>
</tr>
<tr>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0.4pt; padding: 4pt 4pt 4pt 4pt;">ran_vals</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">s</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">292</td>
<td style="vertical-align: top; text-align: left; white-space: nowrap; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">(Intercept)</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.731</td>
<td style="vertical-align: top; text-align: right; white-space: normal; border-style: solid solid solid solid; border-width: 0pt 0.4pt 0.4pt 0pt; padding: 4pt 4pt 4pt 4pt;">0.2  </td>
</tr>
</table>

Congratulations lecturers 1163, 2732 and 700!

---
